8.5 hybrid接口3

1.实验要求

1）R1、R3互访
2）R2、R3互访
3）R1、R4互访
4）R3、R5互访
5）其余之间不能互访

2.SW1配置

[SW1]vlan batch 10 20 30
[SW1]interface GigabitEthernet 0/0/1
[SW1-GigabitEthernet0/0/1]port hybrid pvid vlan 10
//接收数据加入VLAN 10
[SW1-GigabitEthernet0/0/1]port hybrid untagged vlan 10 30
//发送数据时剥离VLAN 10、30

[SW1]interface GigabitEthernet 0/0/2
[SW1-GigabitEthernet0/0/2]port hybrid pvid vlan 20
[SW1-GigabitEthernet0/0/2]port hybrid untagged vlan 20 30

[SW1]interface GigabitEthernet 0/0/3
[SW1-GigabitEthernet0/0/3]port hybrid pvid vlan 30
[SW1-GigabitEthernet0/0/3]port hybrid untagged vlan 10 20 30

[SW1]interface GigabitEthernet 0/0/24
[SW1-GigabitEthernet0/0/24]port hybrid tagged vlan 10 30
//允许VLAN10 、30，并打上标记。

3.SW2配置

[SW2]vlan batch 10 30
[SW2]interface GigabitEthernet 0/0/01
[SW2-GigabitEthernet0/0/1]port hybrid pvid vlan 10
[SW2-GigabitEthernet0/0/1]port hybrid untagged vlan 10
[SW2]interface GigabitEthernet 0/0/2
[SW2-GigabitEthernet0/0/2]port hybrid pvid vlan 30
[SW2-GigabitEthernet0/0/2]port hybrid untagged vlan 30
[SW2]interface GigabitEthernet 0/0/24
[SW2-GigabitEthernet0/0/24]port hybrid tagged vlan 10 30
